Xpert HS-2202T-HV KD1T Standard Size Full Aluminum Servo

Features

• Developed and tuned by World Champion Helicopter Master, Kyle Dahl.
• Global 3D 2017 Competition Winning Servo.
• Ultra High Responsive cyclic algorithm software.

Quick release cable that allows easy and quick installation for all helicopters.

• Brushless motor design provides extremely high speed, top efficiency, and low power consumption.
• 4096 resolution and SIC (Single Integrated Circuit) for the highest performance and durability.
• Light weight design
• All Aluminum case for the best thermal dissipation and durability.
• Strong Metal Gear
• Glitch-free
• Sophisticated error correction
• High-Speed, High-precision 12-bit AD converter and CPU calculation
• Fail safe
• Over current protection
• Over temperature protection
• Start sonorant
• 760us narrow band
• Operating frequency up to 800Hz

Specifications

Type	Standard
Product Name	HS-2202T-HV KD1T Standard Size Full Aluminum Servo
Part Name	HS-2202T-HV
Power Supply	6.0V~8.4V
Speed (sec/ 60°)	@6.0V: 0.047 sec/60° @7.4V: .038 sec/60° @8.4V: .033 sec/60°
Torque (oz/in)	@6.0V: 83.28 oz-in @7.4V: 102.71 oz-in @8.4V: 116.59 oz-in
Torque (kg/cm)	@6.0V: 6.00 kg-cm @7.4V: 7.40 kg-cm @8.4V: 8.40 kg-cm
Dimensions	40×37.80×20 mm
Weight	73.6g
Frequency	200/333 Hz
Range	50~400 Hz
Center Position	760us
Applications	Helicopter Tail
